Martin VDO Atomic Dot user guide 31
Basic Value Function Fade Status
Default
Value
129 - 171 Random
172 - 214 Lightning
215 - 255 Spikes (flash over low light)
Beam P3 Mode
0 - 26 DMX-Mode
Output of beam LED is fully controlled by
channel 1-5
(P3 pixels are ignored)
27 - 228 Mix-Mode
Output of beam LED is defined by mix of:
- Channel 1-5
- P3 pixels
(range 27 to 228 performs cross-fade
between the two)
6
229 - 255 Video-Mode
P3 pixels are used as basis on top of which
channel 1-5 are applied
Snap 0
Control / Settings
0 - 9 No Function
10 - 14 Reset Entire Fixture - 5 sec
15 - 22 No Function
23 Linear Dimming Curve - 1 sec
24 Square Law Dimming Curve - 1 sec
25 Inverse Square Law Dimming Curve - 1 sec
26 S-Curve Dimming Curve - 1 sec
27 - 35 No Function
36 Enable Video Tracking
37 Disable Video Tracking
38 - 58 No Function
59 Strobe Behavior = LED
60 Strobe Behavior = Xenon
7
61 - 255 No Function
Snap 0
FX Select
0 No FX
8
1-255 FX Selection (see table)
Snap 0
FX Speed / Modifier (depending on effect)
0 – 126
Rev Fast → Slow
127 – 128 Stop
9
129 – 255
Slow → Fast
Fade 128
FX Synchronization
10
0 No Sync
Snap 0
