34 Martin VDO Atomic Dot user guide
Basic Value Function Fade Status
Default
Value
video.
Aura Red
17
0 - 255
0 → 100%
Fade 255
Aura Green
18
0 - 255
0 → 100%
Fade 255
Aura Blue
19
0 - 255
0 → 100%
Fade 255
Notes:
x Fixture will automatically reduce intensity to control temperature when running at high
power for too long
DMX mode Extended
Extend
ed
Value Function Fade Status Default
Value
Beam Flash Intensity
0 Blackout
1 - 2
1 - 65535
Minimum → Maximum Intensity
Snap 0
Beam Flash Duration
3
0 - 255
7 → 650 ms
Snap 0
Beam Flash Rate
4
0 - 255
0.289 → 16.67 Hz
Snap 0
Beam Special Effects
0 - 5 No Effect
6 - 42 Ramp Up
43 - 85 Ramp Down
86 - 128 Ramp Up, Down
129 - 171 Random
172 - 214 Lightning
5
215 - 255 Spikes (flash over low light)
Snap 0
Beam P3 Mode
6
0 - 26 DMX-Mode
Output of beam LED is fully controlled by
channel 1-5
(P3 pixels are ignored)
Snap 0
