Martin VDO Atomic Dot user guide 37
Extend
ed
Value Function Fade Status Default
Value
126 - 130 Color 24 - JAS Green
131 - 135 Color 25 - Lime Green
136 - 140 Color 26 - Spring Yellow
141 - 145 Color 27 - Deep Amber
146 - 150 Color 28 - Chrome Orange
151 - 155 Color 29 - Orange
156 - 160 Color 30 - Gold Amber
161 - 165 Color 31 - Millennium Gold
166 - 170 Color 32 - Deep Golden Amber
171 - 175 Color 33 - Flame Red
176 - 180 Color 34 - Magenta
181 - 185 Color 35 - Medium Lavender
186 - 190 Color 36 - White
191 - 214
Color Wheel Rotation Fast → Slow
215 - 219 Color Wheel Rotation Stop (stop on last color)
220 - 243
Color Wheel Rotation Inverse Slow → Fast
244 - 247 Random Colors Fast
248 - 251 Random Colors Medium
252 - 255 Random Colors Slow
Aura P3 Mode
0 - 26 DMX-Mode
Color of Aura LEDs is fully controlled by
channel 17-64 (Aura Red, Green & Blue)
(P3 pixels are ignored)
27 - 228 Mix-Mode
Color of Aura LEDs is defined by mix of:
- Channel 17-64 (Aura Red, Green & Blue)
- P3 pixels
(range 27 to 228 performs cross-fade
between the two)
16
229 - 255 Video-Mode
Color and brightness of Aura LEDs is driven
by P3 pixels, but Aura Red/Green/Blue
channels 17-64 keep ability to "color" the
video.
Snap 0
Aura Red Pixel 1
17
0 - 255
0 → 100%
Fade 255
Aura Green Pixel 1
18
0 - 255
0 → 100%
Fade 255
Aura Blue Pixel 1
19
0 - 255
0 → 100%
Fade 255
20
Aura Red Pixel 2
Fade 255
