Front brake light switch
The front brake light switch is located below the brake lever. Loosen the screw
and move the switch position back and forth to find the point where the lamp is
lit immediately when pressure is applied but before the lever is fully pressed.
Rear brake
Adjusting the rear wheel brake pedal:
The rear brake is a disc brake. To adjust the rear wheel brake pedal, turn the
pedal to the most comfortable position by turning the clamping nut (1). Once
the position is adjusted, lock it with the counter nut (2).
Please keep a guard between 10 and 20 mm (3) of free play.
Warning
If the rear brake pedal has no free play (20-30mm), the rear master
cylinder will be always under pressure. It could overheat and the brakes
may start to bind.
