Masibus MINT Series User Manual

Page | 33
MINT – IO
REF NO: m25A/om/101
Issue No: 11
Counter Capture
40065
BIT1=1 to Capture
Counter for CH.1,
BIT2=1 to Capture
Counter for CH.2, etc
Capture Counter
Registers (swap long)
40033 to 40064
Capture Counter
Registers, Channels 1 to
16 counter holding
registers. Unsigned 32-
bit integers (swap long).
Filter Time
40066
0 = Disable, >0 =
Enable. (x 1msec)
Debounce Time
40067
0 = Disable, >0 =
Enable. (x1ms).
Chatter Time
40068
0 = Disable, >0 =
Enable. (x1ms)
Chatter Count
40069
Chatter Count, max. 250
count
Capture Zero
40070
0 = Disabled (Start From
Capture Count), bit1 =1
auto zero counter 1. bit2
=1 auto zero counter 2.
Counter Mode
40071 – 40086
0=Disable, 1=Up
Counting, 2=Down Count
for CH.1-16
DI Status Word
30085
16 channel Input State –
16 BIT. 1 = ON 0 = OFF
Counter Starts from
stored value during
power OFF.
40087
0 = Disabled (counter
start depends on
Capture Zero bit
selection), bit1 =1 start
from power off counter
value 1. bit2 =1 start
from power off counter
value 2.
