Masibus MINT Series User Manual

Page | 38
MINT – IO
REF NO: m25A/om/101
Issue No: 11
4.2.6 Modbus Address for configuration:
Parameter
Address
Description
Digital Output
00001 – 00016
Channel 1 – 16 DO Coils
1 = Set to ON
0 = Reset to OFF
Line State
10001 – 10016
16 channel line State
1 = Connected 0 = Disconnected
Channel Type
40001 – 40016
Channels 1 – 16 types:
0 = Normal ,1 = Single Pulse
2 = Continuous pulse
DO predefine value
40017
Channel 1 – 16
BIT 1 to BIT 16 , 1 – ON 0 – OFF
DO – Pulse High
level Time
40021 – 40036
Channel 1 – 16 high level time in
ms. 1-500 (x 10msec)
DO – Pulse Low level
Time
40037 – 40052
Channel 1 – 16 low level time in ms.
1-500 (x 10msec)
DO Pulse Predefined
Value
40053 to 40068
Channels 1 to 16 pulse Predefined
value.
In “Continuous Pulse” mode, after
the pulse value reached this
predefined value; the output will be
forced to OFF.
If this value is zero, the pulse
Output will be unlimited.
DO Pulse Predefined
Value Reset
40020
Channel 1 – 16, BIT 1 to BIT 16
1 – Reset
Channel Type
30001 – 30016
Read Only
DO predefine value
30017
Read Only
DO – Pulse High
level Time
30021 – 30036
Read Only
DO – Pulse Low level
Time
30037 – 30052
Read Only
DO Pulse Value
30053 to 30068
Read Only
DO Pulses
30069 to 30084
Channels 1 to 16 – number of
output pulses as per the Predefined
value defined in DO pulse
Predefined value
Line State - Word
30085
16 channel line State – 16 BIT
1 = Connected 0 = Disconnected
