Page | 42
MINT IO
REF NO: m25A/om/101
Issue No: 11
Note:
1
Abnormal Conditions of Process Value
Abnormal Value
Description
32764
Channel Skip
32765
UNDER Value
32766
OVER Value
32767
Channel OPEN Indication
2
Input Type Descriptions
Valu
e
Type Description
Modbus Ranges
Input Range
0
Channel OFF ( Skip )
NA
NA
1
E - Type TC
-2000 to 10000
-200°C to 1000°C
2
J - Type TC
-2000 to 12000
-200°C to 1200°C
3
K - Type TC
-2000 to 13500
-200°C to 1350°C
4
T - Type TC
-2000 to 4000
-200°C to 400°C
5
B - Type TC
4500 to 18000
450°C to 1800°C
6
R - Type TC
0 to 17500
0°C to 1750°C
7
S - Type TC
0 to 17500
0°C to 1750°C
8
N - Type TC
-2000 to 13000
-200°C to 1300°C
9
Pt-1003W
-2000 to 8500
-200°C to 850°C
10
CU-53
-2100 to 2100
-210°C to 210°C
11
NI 120
-800 to 2100
-80°C to 210°C
12
Current
-2000 to +20000
0.000 to 20.000mA
13
Current
-2000 to +20000
4.000 to 20.000mA
14
resistance
0 to 2000
0 to 2000
15
Voltage
-2000 to +20000
-10mV to +50mV
16
Voltage
-2000 to +20000
0 to +100mV
17
Voltage
-2000 to +20000
0 to +250mV
18
Voltage
-2000 to +20000
0 to +5V
19
Voltage
-2000 to +20000
0 to +10 V
