System Description
Symbols
The following symbols may be found on the Rad-87 or packaging and are defined below:
RS-232
Equipotential Ground Terminal
Consult accompanying documents
Nurse Call Interface
WEEE compliant
Mark of Conformity to European Medical Device Directive 93/42/EEC
R
x
Only
Federal law restricts this instrument to sale by or on the order of a
physician (USA audiences only)
Year of manufacture
5%-95% RH
Storage humidity range: 10% to 95%
-40 C
+70 C
+1060 hPa - +500 hPa
7
95 mmHg - 375 mmHg
Storage temperature range: -40˚C to +70˚C
Storage altitude range: 500 mbar to 1060 mbar
Keep dry
Fragile/breakable, handle with care
Indicates wireless Radio signal (wireless radio model only)
EC REP
EU authorized representative
Defi brillation Proof Type BF
Caution
Manufacturer
Electrical Testing Laboratory certification
