2.5 INPUT JACKS
This meter has four input jacks that are protected against overload to the limits. During
use, connect the black test lead to the COM jack and the red test lead as shown below:
FUNCTION RED LEAD CONNECTION INPUT LIMITS
DCV/ACV
Ω
mA
10A
V/Ω
V/Ω
V/Ω
mA
10A
1000V dc or 750V rms ac
250V dc or rms ac
250V dc or rms ac
400mA dc or rms ac
10A dc or rms ac
