2.6 FRONT PANEL
. DISPLAY
. ON/OFF SWITCH
.TRANSISTOR TESTING SOCKET
. FUNCTION SWITCH
. CAPACITANCE OR TEMPERATURE
TESTING SOCKET
. INPUT JACKS
. RS232C SOCKET
. B/L BUTTON
. R-H BUTTON
. DC/AC OR Ω / BUTTON
6
5
4
3
2
7
8
9
1
