-9-
3. OPERATING INSTRUCTION
3.1 VOLTAGE MEASURING
1.
2.
3.
4.
Connect the black test lead to the COM jack and the red test lead to the
V/Ωjack.
Set the function switch at V range and connect test leads across the source or
load under measurement.
Push the DC/AC button to select DCV or ACV measuring mode. (Push the R-H
button to select manual range.)
Read LCD display. The polarity of red test lead connection will be indicated
when making a DC measurement.
3.2 CURRENT MEASURING
