Mastech MAS345 - Temperature Specifications

4.9 AUDIBLE CONTINUITY
Function Description
Built-in buzzer will sound, if resistance is lower than 30Ω.
4.10 DIODE
Function Resolution Test Current Open Circuit Voltage
1mV 25μA 3.0V
4.11 TRANSISTOR
Function Range Base Current Vce
hFE 1 to 1000 10μA 3.0V
-25-
