2.
Set the function switch at Ω range to be used and connect test leads across the
resistance under measurement.
-11-
NOTE:
1.
2.
3.
For resistance above 1MΩ, the meter may take a few seconds to stabilize
reading. This is normal for high resistance measuring.
When the input is not connected, i.e. at open circuit, the figure “OL” will be
displayed and full bar graph appears for the overrange condition.
When checking in-circuit resistance, be sure the circuit under test has all power
removed and all capacitors fully discharged.
3.4 CAPACITANCE MEASURING
