4.6 MEASURING INSULATION
RESISTANCE
(See Fig 4, Fig 5, Fig 6)
Warning
Insulation tests should be
conducted on circuits that
are de-energized. Ensure
circuits are not live before
commencing testing.
Using test clips connect the
meter and the tested circuit,
then press test button for
testing.
