NOTE:
• When only the figure ‘ 1 ’ is
displayed, it indicates overrange
situation.
• When the input is not connected,
i.e. at open circuit, the figure
‘1’ will be displayed for the
overrange condition.
4.10 CONTINUITY TEST (see Fig
9)
4.10.1 Connect the black test lead
to the LOW jack and the red
test lead to the HIGH jack.
