ASSEMBLY INSTRUCTIONS
Lowes.com/masterforge
1
Q
16
K
2
1
O
15
P
K
3
4
1
2
A
A
K
14
B
C
15.Opendoors(U,V).Slidethewoodchipbox(O)
onto the lowest cooking grate supports inside
thesmokerbody(K)andputthewoodchipbox
lid (P) on top.
16. Slide the water bowl (Q) onto the cooking grate
supportsinsidethesmokerbody(K)abovethe
woodchipboxasshown.
14. With the side table (A) in a perpendicular
position, align the slots in the side table with the
side table supports (B, C) and insert. To lock
the side table (A) in the upright position, swing
the side table (A) 90 degrees up, push towards
thebody(K),andpressdownontheside
table (A) near the body until it is fully fastened
in place.
