ASSEMBLE THE T-RAIL
Attach the T-Rail to the Opener
Raise the pulley end of the rail so the rail can sit on the motor unit properly. Attach the rail
to the motor unit by tightening 2 screws. Insert a bolt to the stop bolt hole and secure it with
nut.
Apply the Safety Label
Prepare the Chain
Lay down the chain on the floor, as shown. Do not twist the chain or cable.
CAUTION
• Use only the specified bolts to attach the T-rail to the opener. Any other bolts will cause serious damage
to the opener.
