Attach the Pulley Bracket
Attach the pulley bracket assembly to the end of the
front rail with 2 nuts and bolts.
Align the pulley bracket and rail.
Install the Trolley
Please note the arrow and “M” marking which
indicates this side to the motor unit.
Ensure this side of the trolley is on the
stop bolt hole side of the rail.
Slide the trolley from the back of the
T-rail assembly.
Stop Bolt Hole.
To Motor Unit (Back)
