23
headline bars
continuation tabs
notes
warnings
HANG THE OPENER
headline bars
continuation tabs
notes
warnings
Attach the Hanging Brackets
Hanging brackets should be angled to provide rigid support. Measure the distance from the
motor unit to the structural support. Cut and bend the hanging brackets as required.
For an “open-seam” garage, attach the hanging brackets directly to the joists with 2 lag screws.
Bracket (not included)
Bolts and Nuts (not included)
On a finished ceiling, attach a sturdy metal bracket (not included) to structural supports before installing
the opener.
Attach the Opener to the Hanging Brackets
Attach the opener to the hanging brackets with
two bolts and nuts.
Ensure the T-rail is centred over the door. Remove
the 2x4.
WARNING
To avoid possible serious injury from a falling garage door opener, fasten it securely
to structural supports of the garage. Concrete anchors must be used if installing any
brackets into masonry.
