INSTALL THE DOOR ARMS
model no. 046-0265-2 | contact us 1-800-689-9928
26
INSTALL THE DOOR ARMS
Attach Emergency Release Rope
Thread the red rope through the hole in the trolley release handle and tie an over-hand knot.
Leave the trolley release lever in the released position until further testing is completed.
Connect the Door Arm to Door Bracket
Sectional Door
Connect the curved door arm to the door
bracket with clevis pin and hitch pin.
Engaged Released
One-piece Jamb Door
Connect the straight arm to the door
bracket with clevis pin and hitch pin.
To Next Page
