One-Piece Metal Doors
Drill two 3/16" (5 mm) pilot holes. Use 2 self-threading screws to
secure the door bracket.
One-Piece Wood Doors
For wood doors, drill 5/16" (8 mm) holes through the door and secure
bracket with 5/16 x 2" (8 x 50 mm) carriage bolts, lock washers and nuts
(not included).
Centre the door bracket
on the top of the door.
CAUTION
• Lightweight garage doors are not designed for use with garage door opener must be
equipped with a door reinforcement kit. Check with the garage door manufacturer for
more information. Many door reinforcement kits provide for direct attachment of the clevis
pin and door arm. In this case, you will not need the door bracket, proceed to “Install the
Door Arms” section.
