model no. 046-0265-2 | contact us 1-800-689-9928
INSTALL THE WALL CONSOLE

Mount the user safety instruction label next to the wall console.

Route the wire up the wall and across the ceiling to the opener with wire holders.

Connect the wires to the terminals .
Wires are not polarity sensitive (either wire to either terminal).
White Black
