model no. 046-0265-2 | contact us 1-800-689-9928
CONNECT THE OPENER TO POWER
Permanent Wiring/Hardwire the Opener
Green – Ground
White – Neutral
Black – Hot
Connect conduit wiring to opener wiring with wire nuts (not included). Install the bottom
cover and screws.
Permanent Wiring/Remove the Bushing
Be sure the power cord is unplugged. Cut the
cord about 6" (15 cm) above the bushing.
To Next Page
