MasterCraft csx 220 User Manual

cs X 220
38
19
18
14
13
11
23
20
28
05
35
01 Bow cleat
02 Sirius Satellite Radio antenna (where equipped)
 03 Bowllercushion(where equipped)
04 Circuit breaker panel
05 Steering wheel
 06 Hand-heldreextinguisher
(under helm)
07 Center drain plug (beneath seating)
08 Engine compartment and seacock (sea strainer) access
09 Fire port
 10 Fueltankller
 11 Freshwatertankll
12 Stern cleat
 13 Freshwaterushport
14 Swim platform
15 Blower exhaust (two, under swim platform)
16 Under-platform ladder (where equipped)
17 Telescopic, removable dive ladder (where equipped)
18 Zinc anode bonding system (under swim platform)
19 Transom drain plug (center, beneath swim platform)
20 Underwater lights (four, where equipped, under swim platform)
21 Ski pylon
22 Transom stereo remote (where equipped)
23 Slick Boot wand and switch (where equipped)
24 Stern cleat
25 Batteries (including ON-OFF switch)
26 Battery circuit breaker panel
 27 Fueltankller
28 Anchor light
29 Shower, sink and cooler access; shower wand and switch
30 Shift/throttle control
31 Amp
(where equipped)
32 Subwoofer (where equipped)
33 iPod interface (where equipped)
34 Stereo CD Player (where equipped); Sirius Satellite Radio (where
equipped)
35 Nav/anchor light
36 Instrument panel (details elsewhere in this section)
37 Windshield-mounted mirror
 38 Bowllercushion (where equipped)
39 GPS antenna
40 Bow cleat
41 Bow ladder
42 Anchor
Boats may be equipped with towers, which include a storage box,
red & white dome lights, navigation lights, and may also
have cockpit oodlights and/or Xtreme mirror
Storage space is located:
Under bow seating
Under aft seating
mastercraft 2010 ow n e r ’s m anual • page 4-14
25, 26
01
02
27
34
40
09
39
07
08
21
41
37
03
15
04
06
10
16
17
31, 32, 33
12
22
36
29
24
30
42
