model no. 055-6768-8 | contact us 1-800-689-9928
60
REPLACEMENT PARTS
I.D. NO. Description Size Q’ty I.D. NO. Description Size Q’ty
0831 SHAFT SLEEVE 6# 1 32R9 NUT CHUCK M5*0.8 T=5 2
082J CUSHION 6# 2 32RA NUT CHUCK M6*1.0 T=6 4
082L BOLT 2 32RB NUT CHUCK M8*1.25 T=8 1
082P SCREW STOP 1 32RC NUT CHUCK M12*1.75 T=12 1
082Q LOCK NUT 1 34BN COMPRESSION SPRING 1
083Z CORD CLAMP 6# 1 34NJ UPPER TUBE 2
0CES COMPRESSION SPRING 1 34NK UPPER TUBE 2
0CPD CENTRE BOLT 1 351P BUMPER 1
0D9B ANCHOR BLOCK 1 35QJ LEVER 1
0DT4 ROLLING WHEEL 6# 2 37TB FLAT WASHER φ6*13-1 2
0DT7 BEARING 6# 2 37TC FLAT WASHER φ8*16-2.5 1
0DTZ ARBOR COLLAR 2 3ADN HEX. SOC. HD. CAP BOLT M6*1.0-20 1
0DVJ BLADE WRENCH 1 3ADS HEX. NUT M6*1.0 T=5 2
0FHW COLLAR 1 3ADZ NUT CHUCK M10*1.5 ,T=10 1
0J3Q HEX. WRENCH 5 MM 1 3AE3 FLAT WASHER 1
0J6P FLAT WASHER φ6*16-2 1 3BKA EXTENSION WING (RIGHT) 1
0JAZ WAVE WASHER WW-6 2 3BKB EXTENSION WING (LEFT) 1
0JB0 WAVE WASHER WW-8 4 3BPY CLAMP HANDLE 1
0JBG DISC SPRING WASHER φ12 1 3BSB TABLE BRACKET 1
0JC8 SPRING PIN 1 3DJ8 LOCATING BAR 1
0JCT SPRING PIN 2 3DJG SPACER 2
0JE7 C-RING 1 3DJL SET PLATE 1
0JMN O-RING 1 3DK9 BOLT 1
0JMP O-RING 1 3DKA BOLT 1
0JN6 O-RING 2 3DKF SHAFT-PIVOT 1
0K05 HEX. SOC. TRUSS HD. SCREW M8*1.25-20 4 3DLH FOLLOWER PLATE (RIGHT) 6# 1
0K9Y DRIVE SCREW φ2.3-5 5 3DLJ FOLLOWER PLATE(LEFT) 6# 1
0KR2 LOCK NUT M5*0.8 T=5 2 3DWQ PLATE 1
0KR3 LOCK NUT M6*1.0 T=6 1 3DWT INSERT 1
0KTP CABLE CLAMP 1 3DWV PIN 2
0KUW TERMINAL 4 3DWW LASER SET 6# 1
0S1S COLLAR 1 3DWY PIVOT-SUPPORT 6# 1
20PL CLAMP HANDLE KM# 2 3DWZ LASER PLUNGER HOUSING 6# 1
224U ROLL PIN 2 3F4X SHAFT 1
22A4 LOCKING CABLE TIE 1 3F8Q PLUNGER HOUSING 1
23NX GUARD-CORD 1 3FJH SET PLATE 1
25B1 CR.-RE. TRUSS HD. SCREW M5*0.8-25 1 3FJN FENCE 1
27PQ ROLL PIN 1 3FJP ASSIST-FENCE-R 1
2BQA PLATE 6# 2 3FJQ WRENCH SET 6# 1
2BQG BLANKET WASHER 4 3FJS MOTOR_HANDLE_UP 1
2C0F CONTROLLER ASS’Y 1 3FJT MOTOR_HANDLE_DOWN 1
2D7E COMPRESSION SPRING 1 3FJV ASSIST-FENCE-R 1
2E35 TRIGGER 6# 1 3FM3 SPECIAL BOLT 2
2F39 CLEVIS PIN 1 3FS5 BASE 1
2JTR INSULATING SLEEVE 1 3FS7 SLIDE-BAR SEAT (FRONT) 1
2M0S LIMIT SWITCH 1 3FS8 SEGMENT HANDLE 6# 1
2MC3 ROLL PIN 2 3FSA MITRE BAR 1
2NAH CR.-RE. TRUSS HD. SCREW M4*0.7-8 1 3FSB MITRE BAR 1
2S5C CAUTION LABEL 1 3FSD FRAME ENDCAP,BLACK PLASTIC 6# 3
2S5D WARNING LABEL 1 3FSE FRAME ENDCAP,BLACK PLASTIC 6# 1
2VH5 LINEAR MOTION BEARING 3 3FSF BEARING COVER 3
2VS0 LEAD WIRE ASS’Y 1 3FSG WASHER BEARING 6# 1
2VZ1 RUBBER INSERT 6# 8 3FSU FRONT HOUSING 6# 1
2WK0 COMPRESSION SPRING 1 3FVK LASER_COVER 6# 1
2YR6 SPRING GUARD 1 3FVL COVERLASER_COVER 6# 1
306G BUSHING 1 3G0D HEX.SOCKET HD.CAP SCREWS M6*1.0-16 1
31XE SLIDE PLATE 3 3G0U CLAMP BOLT 6# 1
To Next Page
