REPLACEMENT PARTS
TM
I.D. NO. Description Size Q’ty I.D. NO. Description Size Q’ty
3G0W CLAMP BOLT 6# 1 3HJY LOCK NUT M6*1.0 T=9 2
3G10 KNOB-HANDLE 6# 1 3HJZ FLAT WASHER φ4*8-1 2
3G14 PLUNGER HANDLE 6# 1 3HK1 FLAT WASHER φ12*21-1 1
3G3T PLUNGER HANDLE 6# 1 3HK2 FLAT WASHER φ5*14-1 2
3G3V CLAMP HANDLE 6# 2 3HK4 FLAT WASHER φ4*10-1 1
3G4S VISE ASS’Y 6# 1 3HK6 FLAT WASHER φ6*10-1 3
3GGC COMPRESSION SPRING 1 3HK8 FLAT WASHER 1/4*1/2-3/32 1
3GGE TABLE INSERT 23# 2 3HK9 FLAT WASHER 3/8*29/32-1/8 1
3GGF TILTING SCALE 1 3HMW HEX. SOC. HD. CAP BOLT M6*1.0-16 1
3GGG LOCKING HANDLE 6# 1 3J5W NEEDLE POINTER KU# 1
3GGH SPECIAL BOLT 1 3JCQ INSTRUCTION MANUAL 1
3GGL LOCKING ROD 1 3JDM NEEDLE POINTER 1
3GGS POWER CORD CLAMP 6# 1 3JE7 HEX.SOCKET HD.CAP SCREWS M5*0.8-20 1
3GGT CLAMP-CORD 6# 1 3JQE PLATE(RIGHT) 1
3GJ7 CABLE SHIELD 6# 1 3JQF PLATE(LEFT) 1
3GJA ARM-MITRE 1 3JSU CAUTION LABEL 1
3GJC SHAFT-PIVOT 1 3JSW CAUTION LABEL 1
3GPG PLATE 1 3JSX CAUTION LABEL 1
3GPZ ROCKER SWITCH 1 3JSY CAUTION LABEL 1
3GSS CUTTER SHAFT GUARD 1 3JSZ CAUTION LABEL 1
3GST PC-GUARD 1 3JVQ WARNING LABEL 1
3H1T BRACING PLATE 1 3JT1 WARNING LABEL 1
3H1U LEVER BRACKET 1 3JT2 BAG-DUST ASS’Y 1
3H1V LEVER 1 3JTA LABEL 1
3H38 BUTTON SWITCH 6# 1 3JTB SCALE 1
3H3E TORSION SPRING 1 3JTC BLADE 1
3H3G TABLE 1 3K0U ANCHOR PLATE 1
3H9P POWER CABLE 1 3KJ1 INSULATING SLEEVE 1
3H9T LEAD WIRE ASS’Y 1 3KRJ SOC. TRUSS HD. ROUND NECK SCREW M6*1.0-10 1
3H9U LEAD WIRE ASS’Y 1 3KRL SOC. TRUSS HD. ROUND NECK SCREW M6*1.0-14 1
3HA0 BUTTON KN# 2 3KRN SOC. TRUSS HD. ROUND NECK SCREW M6*1.0-14 1
3HAA KNOB 6# 1 3KTN SOC. ROUND WASHER HD. SCREW M5*0.8-16 2
3HEJ MOTOR ASS’Y 1 3KTP SOC. PAN HD. SCREW M5*0.8-20 1
3HHN CR. RE. COUNT HD. SCREW M5*0.8-12 4 3KTQ SOC. TRUSS HEAD SCREWS M6*1.0-8 1
3HHQ CR. RE. COUNT HD. SCREW M3*0.5-6 2 3KTR SOC. COUNTERSUNK HD. TAPPING SCREWM4*18-16 1
3HHR CR. RE. TRUSS HD. ROUND NECK M5*0.8-12 2 3KTT SOC. COUNTERSUNK HD. TAPPING SCREWM4*18-25 1
SCREW 3KTU SOC. COUNTERSUNK HD. TAPPING SCREWM4*16-20 4
3HHX CR.RE. PAN HD. TAPPING SCREWM4*18-16 2 3KTV SOC. BUTTON HEAD CAP SCREWS M5*0.8-16 1
3HJ0 CR.RE. PAN HD. TAPPING SCREWM3*24-8 1 3KTW SOCKET TRUSS HEAD SCREWS M4*0.7-10 6
3HJ4 CR. RE. PAN HD. SCREW M4*0.7-6 2 3KTX SOC. BUTTON HEAD CAP SCREWS M5*0.8-6 3
3HJ5 CR. RE. PAN HD. SCREW M5*0.8-6 3 3KTZ SOCKET FLAT HEAD SCREW M4*0.7-8 4
3HJA CR. RE. PAN HD. SCREW M5*0.8-25 1 3KU0 SOCKET FLAT HEAD SCREW M6*1.0-20 1
3HJE HEX. SOC. SET SCREW M6*1.0-16 1 3KU2 SOC. PAN HEAD SCREW M6*1.0-16 4
3HJF HEX. SOC. SET SCREW M6*1.0-16 2 3KU3 SOC. PAN HEAD SCREW M5*0.8-45 1
3HJG HEX. SOC. SET SCREW M6*1.0-10 2 3KU4 SOCKET PAN HEAD SCREW M5*0.8-8 6
3HJH HEX.SOCKET HD.CAP SCREWS M5*0.8-40 5 3KU5 SOCKET PAN HEAD SCREW M4*0.7-8 2
3HJK HEX.SOCKET HD.CAP SCREWS M6*1.0-12 2 3KU6 SOC. PAN HD. SCREW M4*0.7-12 1
3HJL HEX.SOCKET HD.CAP SCREWS M5*0.8-10 3 3KU9 SOCKET PAN HD. SCREW M5*0.8-16 4
3HJU HEX WASHER HD BOLT M8*1.25-20 1 3KUA SOC. PAN HEAD SCREW M5*0.8-55 2
3HJV HEX. HD. BOLT M6*1.0-25 2 3KUB SOC. PAN HEAD ROUND NECK SCREW M6*1.0-12 1
3HJW HEX. NUT M5*0.8,T=4 1 3KZX TORSION SPRING 1
3HJX SELF-LOCKING RING 2
