Mastervolt chargemaster plus 12/100-3 User Manual

23
Value
Meaning
Adjustable range
Output 2
Battery high
DC output voltage is too high
(read only)
Battery low
DC output voltage is too low
(read only)
Reverse polarity
DC + and DC –are connected in reverse (this will damage the charger)
(read only)
Smart terminal
Battery high
DC output voltage is too high
(read only)
Battery low
DC output voltage is too low
(read only)
Reverse polarity
DC + and DC –are connected in reverse (this will damage the charger)
(read only)
5.2.8 History
This menu shows the absolute maximum readings.
Value
Meaning
Adjustable. Range
Charger
Days running
Total run time in charger mode
(read only)
Output 1
Highest voltage
Highest detected DC voltage output 1
(read only)
Lowest voltage
Lowest detected DC voltage output 1
(read only)
Total Ah’s
Total charged Ah’s
(read only)
Output 2
Highest voltage
Highest detected DC voltage output 1
(read only)
Lowest voltage
Lowest detected DC voltage output 1
(read only)
Total Ah’s
Total charged Ah’s
(read only)
Smart terminal
Highest voltage
Highest detected DC voltage output 1
(read only)
Lowest voltage
Lowest detected DC voltage output 1
(read only)
Total Ah’s
Total charged Ah’s
(read only)
Total Ah’s in
Total charged Ah’s using the smart terminal as input
(read only)
5.2.9 Configuration
Below parameters can be changed via the MasterBus network by means of a remote control panel or by means of an interface
connected to a PC with MasterAdjust software. See applicable user’s manuals for details.
Value
Meaning
Factory setting
Adjustable. Range
Device
Language
Menu language of this device
English
EN, NL, DE, FR, ES,
IT, NO, SV, FI, DA
Name
Name of this device. This name will be recognized by all
devices connected to the MasterBus
CHG
ChargeMaster
0-12 chars
MB
communication
Select if MasterBus communication is available when
only DC power is available.
Smart on
Smart on, Always on
Charger
Method
Charge method
3-Step +
3-Step+, constant
voltage
Maximum current
Maximum DC output current
Depending on
model, 100%
Depending on model
20-100%
Battery type
Type of battery
Flooded
User defined, AGM,
GEL, Flooded, AGM
Spiral, Flooded
traction, Flooded
calcium, Mli
