8 ORDERING INFORMATION
8.1 MASTERBUS INSTALLATION COMPONENTS
Part number
Description
77040000
MasterBus terminating device
77040020
MasterBus connection cable (UTP patch cable), 0,2m / 0.6ft
77040050
MasterBus connection cable (UTP patch cable), 0,5m / 1.6ft
77040100
MasterBus connection cable (UTP patch cable), 1,0m / 3.3ft
77040300
MasterBus connection cable (UTP patch cable), 3,0m / 10ft
77040600
MasterBus connection cable (UTP patch cable), 6,0m / 20ft
77041000
MasterBus connection cable (UTP patch cable), 10m / 33ft
77041500
MasterBus connection cable (UTP patch cable), 15m / 49ft
77042500
MasterBus connection cable (UTP patch cable), 25m / 82ft
77050100
100m / 330ft MasterBus cable (UTP cable)
77050200
50 pcs. modular jacks
77050000
Complete set to assemble UTP patch cables. Delivery includes: 100m / 330ft UTP cable, 50 pcs. modular
jacks and crimping tool
77030100
MasterConnect USB interface, required as interface between your PC and the MasterBus when using
MasterAdjust software.
77010310
EasyView 5, Touch screen to control and monitor all MasterBus products
77020110
MasterShunt 500, DC-distribution module for exact readout of battery voltage, charge / discharge current,
and state of charge on the display of the ChargeMaster Plus. continuous rating: 250A, peak current: 500A
8.2 MISCELLANEOUS
Part number
Description
604015
ATC Fuse 15A (2 pcs)
77049050
ANL Fuse 50A
77049080
ANL Fuse 80A
77049100
ANL Fuse 100A
77049125
ANL Fuse 125A
607006
ANL Fuse base
701
Battery switch 275A with knob
6387000600
Double pole automatic circuit breaker DPN 6A-B, 1P+N
6387001000
Double pole automatic circuit breaker DPN 10A-B, 1P+N
6387001600
Double pole automatic circuit breaker DPN 16A-B, 1P+N
6385401610
Double pole automatic circuit breaker and earth leakage switch DPN VIGI 16A / B / 16mA, 1P + N
41500500*
Battery temperature sensor, incl. 6 meter / 19 ft cable
* standard included with the delivery of the ChargeMaster Plus
Mastervolt can offer a wide range of products for your electrical installation, including an extended program of components for
your MasterBus network, both AGM and gel batteries, shore power connections, DC distribution kits and many more
See our website www.mastervolt.com for an extensive overview of all our products
