CombiMaster 120V Series – User and Installation Manual
8.3 Transfer system specifications
Model
All models
AC input (switched)
30A
AC input fuse
Yes, resettable thermal fuse
AC output
Max connected continuous load: 40A*
Transfer speed
10ms for narrow input range, 20ms for wide range
Transfer voltage range
90-140V
Transfer frequency range
40-65Hz
Power sharing
Yes
AC IN support
Yes
Auto-synchronize with AC input
Yes
* Exceeding the max. allowable output current may damage the CombiMaster Inverter/Charger.
8.4 Miscellaneous
Model
All models
Dimensions, h×w×d
17.6 × 11.2 × 6.1 inch [448 × 284 × 155 mm]
Weight
20.5 lb [9.3 kg]
Protection degree
IP 23 vertical wall mounted, IP 21 horizontal tabletop mounted
Safety class
IEC protection class I
Operating temperature
14°F to 140°F, derating above 104°F
[-10°C to 60°C, derating above 40°C]
Storage temperature
-22°F to 158°F [-30 to 70°C]
Pollution degree
3
Relative humidity
Max 95% relative humidity, not condensing.
Standards, approvals & listings
UL1741, UL1236, FCC Class B
Front panel display
Yes, shows AC input sate, Inverter state, charger state
Battery temperature sensor
Yes
Cooling
Vario fans
Parallel stacking
No
3-phase configuration
No
MasterBus powering
Yes
LEN (Load Equivalence Number)
0
Protections
AC input:
AC IN limit
Adjustable
Frequency monitoring
Relay disconnects when frequency is out of range
Voltage monitoring
Relay disconnects when voltage is out of range
Output:
Short circuit protection
Yes (inverter only)
Overload protection
Yes (integrated resettable thermal fuse)
Over temperature protection
Yes
AC backfeed protection
Yes
