Mastervolt MASS COMBI 12/1600-60

TECHNICAL DATA
EN / Mass Combi 12/1600-60; 12/2200-100; 24/1800-35; 24/2600-60 / January 2015 35
9 TECHNICAL DATA
9.1 SPECIFICATIONS INVERTER
Model Mass Combi 12/1600-60 12/2200-100 24/1800-35 24/2600-60
Part number 36011600 36012200 36021800 36022600
DC input
Nominal battery voltage 12V 12V 24V 24V
Operating input voltage range 10.0 – 15.0V 10.0 – 15.0V 19.0 – 31.0V 19.0 – 31.0V
Absolute maximum voltage range
(No defects)
0.0 – 16.0V 0.0 – 16.0V 0.0 – 32.0 V 0.0 – 32.0 V
Low battery switch off* (1-30 sec delay) 10.0V ±5% 10.0V ±5% 19.0V ±5% 19.0V ±5%
Low battery switch on* 11.0V ±5% 11.0V ±5% 22.0V ±5% 22.0V ±5%
High battery switch off* (No delay) 15.0V ±5% 15.0V ±5% 31.0V ±5% 31.0V ±5%
High battery switch on* 14.5V ±5% 14.5V ±5% 29.5V ±5% 29.5V ±5%
Max. ripple allowed on DC (No defects) 5 % RMS 5 % RMS 5 % RMS 5 % RMS
Nominal current at full load 160A 220A 90A 130A
Maximum peak current 240A 400A 120A 200A
Recommended Fuse 175A 250A 100A 160A
Wire size (up to 2m/6ft) 50mm²/ AWG0 70mm²/ AWG2/0 35mm²/ AWG2 50mm²/ AWG0
Recommended batteries >160Ah >240Ah >85Ah >140Ah
DC No load power consumption
Off mode 0mA 0mA 0mA 0mA
High power mode 230V / 0A out < 9W < 9W < 9W < 9W
Economic mode, 208V / 0A out < 8W < 8W < 8W < 8W
Idle mode, 5 pulses per 2½ sec < 0,5W < 0,5W < 0,5W < 0,5W
AC output
Inverter output voltage (± 5 %) 230V@I
AC
≤7.0A 230V@I
AC
≤9.6A
200V@I
AC
=10.9A
230V@I
AC
≤7.8A 230V@I
AC
≤11.3A
Wave form True sine wave, max 5% distortion, 2½% typical
Frequency 50Hz/60Hz +/– 0.05% (adjustable by DIP switch)
Maximum output power (AC-out: 230V, resistive load)
Cont. power inverter
@T
amb
= 25˚C, cos phi = 1
1600W 2150W 1800W 2550W
Cont. power inverter
@T
amb
= 40˚C, cos phi = 1
1200W 1800W 1400W 2000W
Surge capability (5 sec, resistive load) 3000W 4000W 3000W 4000W
Output power vs. ambient temperature >25°C / 77°F derating –1.5% per °C / –2.7% per °F,
Shutdown at 80°C / 176°F internal temperature.
Efficiency (100VA up to Cont. power inverter
@T
amb
= 25˚C, cos phi = 1)
≥90% ≥90% ≥90% ≥90%
Load power factor range All power factors allowed
Protections Over temperature, overload, short circuit, AC on output, high battery, low
battery.
* Adjustable by means of MasterAdjust software
