Mastervolt MASS COMBI 12/1600-60

TECHNICAL DATA
38 January 2015 / Mass Combi 12/1600-60; 12/2200-100; 24/1800-35; 24/2600-60 / EN
9.4 DIMENSIONS
Figure 31: Dimensions in mm [inch] of the Mass Combi 12/1600-60 and 24/1800-35
Figure 32: Dimensions in mm of the MasterBus – Combi interface
4,50
6944
33
33
6
78
32
318 [12.5]
300 [11.8]
242 [9.5]
316.5 [12.5]
33.5
[1.3]
20.5 [0.8]
143 [5.6]
13
[0.5]
156 [6.1]
35
[1.4]
378.5 [14.9]
