1 GENERAL INFORMATION
1.1 USE OF THIS MANUAL
This manual serves as a guideline for the safe and
effective operation, maintenance and possible correction
of minor malfunctions of the Mass Combi.
It is therefore obligatory that every person who works on or
with the Mass Combi must be completely familiar with the
contents of this manual, and that he/she carefully follows
the instructions contained herein.
Installation of, and work on the Mass Combi, may be
carried out only by qualified, authorised and trained
personnel, consistent with the locally applicable standards
and taking into consideration the safety guidelines and
measures (chapter 2 of this manual).
Keep this manual at a secure place!
The English version has 44 pages.
1.2 GUARANTEE SPECIFICATIONS
Mastervolt guarantees that this unit has been built
according to the legally applicable standards and
specifications. Should work take place, which is not in
accordance with the guidelines, instructions and
specifications contained in this user’s manual, then
damage may occur and/or the unit may not fulfil its
specifications. All of these matters may mean that the
guarantee becomes invalid.
The guarantee is limited to the costs of repair and/or
replacement of the product. Costs for installation labor or
shipping of the defective parts are not covered by this
guarantee.
1.3 VALIDITY OF THIS MANUAL
Copyright © 2015 Mastervolt. All rights reserved.
Reproduction, transfer, distribution or storage of part or all
of the contents in this document in any form without the
prior written permission of Mastervolt is prohibited.
All of the specifications, provisions and instructions
contained in this manual apply solely to standard versions
of the Mass Combi delivered by Mastervolt.
This manual is only valid for the following models:
Part number Description
36011600 Mass Combi 12/1600-60 / 230V
36012200 Mass Combi 12/2200-100 / 230V
36021800 Mass Combi 24/1800-35 / 230V
36022600 Mass Combi 24/2600-60 / 230V
For other models see other manuals available on our
website: www.mastervolt.com
1.4 QUALITY
During their production and prior to their delivery, all of our
units are tested and inspected. The standard guarantee
period is two years after date of purchase.
1.5 LIABILITY
Mastervolt can accept no liability for:
 consequential damage due to use of the Mass Combi;
 possible errors in the manuals and the results thereof.
1.6 IDENTIFICATION LABEL
Figure 1: Identification label
The identification label is located at the right-hand side of
the Mass Combi (see figure 1). Important technical
information required for service, maintenance & secondary
delivery of parts can be derived from the identification
label.
CAUTION!
Never remove the identification label.
1.7 CHANGES TO THE MASS COMBI
Changes to the Mass Combi may be carried out only after
obtaining the written permission of Mastervolt. This is not
applicable for DIP-switches (see chapter 6) which are
used for making user settings.
serial no: E821A0019
PartNo: 36012200
Type: Mass Combi 12V/2200-100A 230V
Input: Charger mode input: 180 - 265Vac
Output: 12Vdc - 100Adc
Output: Inverter mode input: 12V-220Adc
Output: 230Vac, 50/60Hz
Design by Mastervolt - Made in the PRC
IP23
E821A0019
Apparatus version
