Mastervolt MASS COMBI 12/1600-60

TECHNICAL DATA
36 January 2015 / Mass Combi 12/1600-60; 12/2200-100; 24/1800-35; 24/2600-60 / EN
9.2 SPECIFICATIONS CHARGER
Model Mass Combi 12/1600-60 12/2200-100 24/1800-35 24/2600-60
AC input
Nominal voltage / frequency 230V 50/60Hz 230V 50/60Hz 230V 50/60Hz 230V 50/60Hz
Input voltage, 100 % output 207 … 265VAC 207 … 265VAC 207 … 265VAC 207 … 265VAC
Input voltage, reduced output power 180 … 207VAC 180 … 207VAC 180 … 207VAC 180 … 207VAC
Absolute maximum voltage range 0 … 265VAC 0 … 265VAC 0 … 265VAC 0 … 265VAC
Input frequency range 45 … 65Hz 45 … 65Hz 45 … 65Hz 45 … 65Hz
Absolute maximum frequency range 0 … 70Hz 0 … 70Hz 0 … 70Hz 0 … 70Hz
Nominal input current (@230V) 4.5 A 7.2 A 5.2 A 8.5 A
Input phase Single phase, 3 wire system
Insulation class Class I Class I Class I Class I
Power factor > 0,98 > 0,98 > 0,98 > 0,98
Harmonic distortion THD 3% 3% 3% 3%
Efficiency at full output > 85% > 85% > 85% > 85%
No–load power consumption < 15W < 15W < 15W < 15W
Model Mass Combi 12/1600-60 12/2200-100 24/1800-35 24/2600-60
DC output
Nominal output voltage 12VDC
(0…15.5VDC)*
12VDC
(0…15.5VDC)*
24VDC
(0…31.0VDC)*
24VDC
(0…31.0VDC)*
Max. charge current
@T
amb
= 25˚C
60A
@V
DC
≤ 14.25V
100A
@V
DC
≤ 14.25V
35A
@V
DC
≤ 28.5V
60A
@V
DC
≤ 28.5V
Max. charge current
@T
amb
= 40˚C
50A
@V
DC
≤ 14.25V
65A
@V
DC
≤ 14.25V
30A
@V
DC
≤ 28.5V
45A
@V
DC
≤ 28.5V
Second charge output: 5A 5A 5A 5A
Charge characteristic Three-step plus, fully automatic, IUoUo, Equalize
Battery voltage sense Automatic voltage compensation
Protections Short circuit (current is reduced to 25% of I-max)
Equalize mode, max. output current: 4A 10A 3A 6A
Equalize mode, max. output voltage: 15,5VDC 15,5VDC 31.0VDC 31.0VDC
Equalize mode, maximum duration: 6 hrs. 6 hrs. 6 hrs. 6 hrs.
Model Mass Combi 12/1600-60 12/2200-100 24/1800-35 24/2600-60
Factory settings
Return Amps* 6% of maximum output current 6% of maximum output current
Max bulk, abs timer* 6 hours 6 hours 6 hours 6 hours
Return amps timer* 15 minutes 15 minutes 15 minutes 15 minutes
Return to bulk voltage* 12.80V 12.80V 25.60V 25.60V
Return to bulk delay time* 30 seconds 30 seconds 30 seconds 30 seconds
Battery temperature compensation –30mV per °C / –17mV per °F –60mV per °C / –33mV per °F
Battery types Flooded Gel AGM/ Spiral Traction **
Bulk 14.40V / 28.80V 14.40V / 28.8V 14.60V / 29.20V
Charge voltage Absorption* 14.25V / 28,50V 14.25V / 28.50V 14.45V / 28.90V
Charge voltage Float* 13.25V / 26.50V 13.80V / 27.20V 13.25V / 26.50V
Constant voltage charging (Forced float) 13.25V / 26.50V 13.80V / 27.20V 13.25V / 26.50V
* Adjustable by means of MasterAdjust software.
** Traction max ABS/BULK time + 120min.
