8.3 CONSOLE ERROR CODES
CHAPTER 8: TROUBLESHOOTING
CODE DESCRIPTION CONDITION SOLUTION
01AC Electro magnet over current. The electro magnet current is between 1.6 - 2.0
amps for a continuous 60 seconds or over 2.0
amps for 1 second.
1. Check the connection of the electro
magnet wire.
2. Check that the resistance on the
electro magnet. It should be 13.5 (+/-
5%)ohmsundernormalconditions.
01AF The electro magnet is
disconnected.
The electro magnet current <200mA for over 2
seconds.
1. Check the connection of the electro
magnet wire.
2. Check that the resistance on the
electro magnet. It should be 13.5 (+/-
5%)ohmsundernormalconditions.
02A0 Encoder error. In the workout, the speed is not detected by the
proximity sensor for 5 continuous seconds.
1. Check the connection of the sensor.
2. Turn the pedal and check if LED D35
on the LCB flashes.
02BE DC brake error. The brakes in the lock position, but speed is not
zero for 5 continuous seconds.
1. Check the connection of the sensor.
2. Check the brake.
02BF DC brake over current. The brake current is over 1 amp for 3
continuous seconds.
1. Check the connection of the sensor.
2. Check the brake impedance.
02C0 DC brake in manual mode. The brake is in the unlocked position when in
standby mode.
1. Check the position of the brake,
change to the locked position.
2. Replace the brake.
02C1 Speed tracking error. The speed tracking accuracy is off by over 10
RPMs for 20 continuous seconds.
1. Check the resistance system.
2. Check the LCB.
0440 Timeout packet received. Over 500 messages. LCB cannot receive any
more data.
1. Check the connection of the console
cable at the LCB and UCB. Replace
the UCB, LCB, or CC as needed.
0441 Correct packet received, but the
LCB has no function.
LCB not supporting the command. 1. Check the UCB and LCB software
versions are compatible.
04A0 Communication disconnected. There is a packet gap of over 5 seconds 1. Check the connection of the console
cable at the LCB and UCB. Replace
the UCB, LCB, or CC as needed.
04B0 UCB no communication response. LCB has no message to return to the UCB for
over 5 seconds.
1. Check LED6 on the LCB. If LED6
is blinking, replace the UCB or console
cable. If LED6 is not blinking, replace
the LCB.
0249 Fan over current. The fan control current >..14 amps for 5
continuous seconds.
1. Check to see if the fan is running.
024A Safety switch error. No data received for over 5 seconds. Check the safety switch communication
wire.
024B One step sensor error. The speed is not zero, and the system cannot
detect a signal from the step sensor for 10
seconds.
1. Check the connection of the step.
2. Use metal to touch the sensor wire
and check if LCB LED D8 is lit. It is
normally off.
