Matrix G7-S13-02 User Manual

25
CHAPTER 5
：
PARTS REPLACEMENT
5.9 HEAD&SEAT&BACK PAD
1) Remove 4 screws under the seat on both sides to replace the seat pad(Figure A).
2) Remove upper 2 screws to replace the head pad (Figure B).
3) Remove lower 2 screws to replace the back pad (Figure B).
FIGURE A
FIGURE B

Matrix G7-S13-02 Specifications

General

Brand	Matrix
Model	G7-S13-02
Category	Fitness Equipment
Language	English
