Matrix G7-S13-02 User Manual

29
CHAPTER 6
：
PARTS LIST
Part List
SAP No.
SAP Description
Control board
1000096514
Control Board;Matrix;;H102;S1.60;;GM40;
Sensor
1000096531
Sensor;;;;;24AWG;1200mm;OKIx3+XHS-5Y;
Adjustable pin
1000398254
Adjustment Pin Assembly;Assembly;;weight
Snap ring
1000102910
Snap Ring;External C-Shaped;S-12;;BED;
Adjustable rod
1000413887
Incremental Adjustable Rod-Exreawork;Inc
Fixing axle
1000408504
Fixing Axle;Steel Rope Head;Short;45#;Ch
Magnet
1000232864
Permanent Magnet;;;;;1500gauss;Pull pin;
Chair grip
1000211102
grip-Extrawork;seat chair;;muffle;31.8x5
Back grip
1000427175
Slider Bar Arm Sub;BACK PAD;;;;Planet Fi
Pull pin
1000406193
Pull Pin;ADJ;;42CrMo;White Zinc;GM118-KM
Cover ( aluminum )
1000424165
Cover;Frame;U;painting;;Black Matte;GM11
Cover ( ABS )
1000397869
Cover;;up;ABS/PA757;Deep Grey;740.0x173.
Cover right
098985
Cover;;Right-Front;limpid ABS;;;GM40;
Cover left
098988
Cover;;Left-Front;ABS/PA757;Limpid;;GM40
Cover back
1000397883
Cover;;back;ABS/PA757;Limpid;1104.8x648.
Steel rope for ITC
1000403323
Steel Rope-Extrawork;Steel Rope;;Press R
Steel rope for frame
1000403324
Steel Rope-Extrawork;Steel Rope;;Press R
Weight plate
096088
Weight plate set;Semi-Assy;12.5 lb;GM41;
Pulley
1000397609
Pulley;;;NYLON 66+G30%(Anti-fire);Black;
Con rod
1000398860
CON Rod;Seat Adjustment;ADC12;;Black Mat
Note : The parts list of Seat&Back&Head Pad is based on your color; please contact us for more information.
