Matrix T5X-04 User Manual

66
FIGURE G FIGURE H
10.4 ASSEMBLY INSTRUCTIONS - TV - CONTINUED
5) Remove the back of the console and install the TV Mounting Bracket using the 4 screws / washers from the bracket kit (Figure E).
6) Install the TV to the TV Mounting Bracket using the 4 screws shipped in the back of the TV (Figure F).
7) Run the coax cable from the console to the back of the TV (Figure G).
8) Check to make sure the TV power wire is plugged into the console (Figure H).
FIGURE E FIGURE F
CHAPTER 10: TREADMILL SPECIFICATIONS AND ASSEMBLY GUIDE
