10.5 RF900/863 RECEIVER INSTALLATION - CONTINUED
CHAPTER 10: SPECIFICATIONS AND ASSEMBLY GUIDE
FIGURE DFIGURE C
FIGURE BFIGURE A
B. 5X RF900/863 Receiver Assembly
1. Connect the Transmitter, TV or other audio sources, receiver, console (Figure A & B). Note: Connect receiver cable to CSAFE port of console
(Figure B).
2. Connect the earphone to Programmer (Figure C).
3. Input audio sources of the TV or PC to Transmitter (Figure D).

Matrix T5X GROUP TRAINING Specifications

General

Brand	Matrix
Model	T5X GROUP TRAINING
Category	Music Mixer
Language	English
