Connecting video sources to Matrox Rapixo CXP 29
This is a typical sequence for the LED states on your Matrox Rapixo CXP. Refer
to the CoaXPress LEDs section in Appendix B: Technical information for the
complete list of possible LED states.
The following identifies the different timing used to define the LED flash or pulse
states that can occur:
LED indication Hz Timing (+/- 20%)
Fast flash 12.5 20 msecs on, 60 msecs off
Slow flash 0.5 1 sec on, 1 sec off
Slow pulse 1 200 msecs on, 800 msecs off
