Matrox Rapixo CXP - Electrical Specifications

60 Appendix B: Technical information
Electrical specifications
The following table describes electrical specifications for the Matrox Rapixo CXP.
The following table describes the specifications for the auxiliary I/O signals on
Matrox Rapixo CXP.
Operating voltage and current for Matrox Rapixo CXP
Matrox Rapixo CXP Typical: 3.3 V, 0.1 A mA (330 mW)
Typical 12.0 V, 1.4 A (17 W)
Max. PoCXP 18.5 - 24.0 V, 700 mA: 13 W (Current drawn from the internal auxiliary 12 V power connector.
Power is not dissipated by the board; it is only used by the video source).
Total dissipated by the board: 0.33 W + 17 W =17.33 W (typical)
Total dissipated by board and PoCXP video sources = 17.33 W + (4 * 17 W) = 85.33 W (typical)
I/O Specifications
Input signals in LVDS
format
100 Ohm differential termination.
Input voltage on the (+) or (-) pin: -4 V (min) to +5 V (max).
Maximum differential input: 3 V.
Output signals in LVDS
format
Expecting a load of 100 Ohms.
Differential output voltage (with load of 100 Ohm): 250 mV (min) to 450 mV (max).
Offset voltage (common-mode): 1.125 V (min) to 1.375 V (max).
Input signals in TTL format No series termination.
Pulled up to 3.3 V with 4.7 KOhm.
Clamped to -0.7 V to +5.7 V.
Input voltage: low of 0.8 V (max); high of 2.0 V (min).
Output signals in TTL
format
27 Ohm series termination.
High-level output current: -32 mA (max).
Low-level output current: +64 mA (max).
High-level output voltage: 2.0 V (min).
Low-level output voltage: 0.55 V (max).
Opto-coupled input signals 511 Ohm series termination (connected on the anode inputs of the opto-coupler device).
High-level Input current threshold: 5 mA (min) to 15 mA (max) (6.3 mA to 10 mA recommended).
Input voltage: low (V
il
) of 0.8 V (max); high (V
ih
) of 4.71 V (min) to 9.165 V (max).
Input forward voltage (at 25 degrees C): 1.3 V (min), 1.8 V (max).
Propagation delay (at 25 degrees C): 100 ns (max).
