Dimensions and environmental specifications 61
Dimensions and environmental
specifications
• Dimensions of all Matrox Rapixo CXP boards: 16.76 L x 11.12 H x 1.871 W cm
(6.6" x 4.376" x 0.737") from bottom edge of goldfinger to top edge of board.
These values respect the dimensions of a PCIe half-length board.
• Ventilation: 200 LFM over board(s) (through the heat sink).
• Minimum/maximum ambient operating temperature
*
: 0°C to 55°C
(32°F to 131°F).
• Minimum/maximum storage temperature: -40°C to 75°C (-40°F to 167°F).
• Operating relative humidity: up to 95% relative humidity (non-condensing).
• Storage humidity: up to 95% relative humidity (non-condensing).
*. In the vicinity of the board.
