Board summary 59
• Has 4 quadrature decoders. Each supports external 5 V linear or rotary encoders
with quadrature output
*
, and frequencies of up to 50MHz.
• Has 4 general timers. Each timer is a 16-bit timer that can count up to 65,535
clock ticks before resetting. Each timer uses 125 MHz internal clock source.
• Supports coaxial cable lengths of up to 60m running at 6.25 Gbits/sec and 40m
running at 12.5 Gbits/sec, depending on the number of cameras connected. See
Appendix 4: Performance for more information.
• Has a CoaXPress LED for each CoaXPress input connector, to identify the status
and activity of each connected device.
• Has 4 board status LEDs: board-power good, board configuration,
PCIe speed/#lanes, and fallback board configuration.
• Has a fanless design (only Quad CXP-6/Quad CXP-12).
• Support for MIL license fingerprint and storage.
*. Maximum differential swing of 3 V.
