MATSONIC MS7157C - Key to Mainboard Components

16
Key to Mainboard Components
Component Description
SOCKET-370 Socket for Intel FC-PGA Celeron or Cyrix
Joshua processor
DIMM1, 2, 3 Slots for 168-pin memory modules
IDE1, 2 Primary and secondary IDE channels
FDD1 Connector for floppy disk drives
AGP1 Slot for AGP graphics adapter
PCI 1, 2, 3, 4 3 x 32-bit PCI expansion slot
ISA1 8/16-bit ISA expansion slot
ATX1 Connector for ATX power supply
CPUFAN1 Power connector for CPU cooling fan
PWRFAN1 Power connector for case cooling fan
SIR1 Connector for optional IR port
PANEL1 Panel connector for switches and indicators
CD1 Audio connector for optional CD-ROM drive
CD2 Auxiliary audio connector for optional CD-ROM
drive
SPDIF1 In/Out connector for 24-bit digital audio
WOL1 Wake up connector for network adapter
WOM1 Wake up connector for fax/modem card
JP1 Clear CMOS memory jumper
JP2 Keyboard power on jumper
JP7 Enable Suspend-to-RAM jumper
JP8 Enable Flash BIOS jumper
JP9 Set system bus frequency jumper (100MHz)
JP10 Set system bus frequency jumper (133MHz)
JP11
JP12
JP13
Set CPU type for Socket-370 jumper.
JP15 Automatic (BIOS)/manual CPU core voltage
and multiplier ratio configuration jumper
JP16
Connector for two-color LED
J1 Connector for fax/modem adapter card
VID Set CPU core voltage jumpers
BF Set CPU multiplier ratio jumpers
LED1* Onboard 3VSB LED for SDRAM
LED2** Onboard Power LED
