73
Pin Settings
Volt. VID0 VID1 VID2 VID3 VID4
2.8V All open All open All open 2-3 All open
2.7V 2-3 2-3 2-3 All open All open
2.6V All open 2-3 2-3 All open All open
2.5V 2-3 All open 2-3 All open All open
2.4V All open All open 2-3 All open All open
2.3V 2-3 2-3 All open All open All open
2.2V All open 2-3 All open All open All open
2.1V 2-3 All open All open All open All open
*Auto: When all 1-2 pins are shorted, the core voltage will automatically
be determined.
BF: Set system bus multiplier ratio jumpers
Use this 3 x 4-pin jumper set to manually set the
system bus multiplier ratio. See later in this
chapter for information on the system bus
multiplier ratio setting required for the processor
that you have installed.
Pin Settings
Ratio BF1 BF2 BF3 BF4
Auto* 1-2 1-2 1-2 1-2
2 2-3 2-3 2-3 2-3
4 2-3 All open 2-3 2-3
3 2-3 2-3 All open 2-3
5 2-3 All open All open 2-3
2.5 2-3 2-3 2-3 All open
4.5 2-3 All open 2-3 All open
3.5 2-3 2-3 All open All open
5.5 2-3 All open All open All open
6 All open 2-3 2-3 2-3
8 All open All open 2-3 2-3
7 All open 2-3 All open 2-3
Res. All open All open All open 2-3
6.5 All open 2-3 2-3 All open
1.5 All open All open 2-3 2-3
7.5 All open 2-3 All open All open
2 All open All open All open All open
*Auto: When all 1-2 pins are shorted, the system bus multiplier ratio will
automatically be determined.
BF1
BF4
1 2 3
