Chapter 3 Installation
- 28 -
Step
Item Task
5 Confirming drying
hopper condition
Be sure that adjusting fasteners (2 pieces) or handle (1 piece) fastening
cleaning door of drying hopper cylindrical section are securely set as
shown in Figure.
(Only for HD-75～300)
Adjusting
fasteners
Picture 30
６
Moving the drying
hopper
As picture 31 shows, be sure that hook load lifting rope (with hooks) to
fasten the hook board and lift and move drying hopper to base with
using hoist at your company.
Picture 31
【Notice！】Use the lifting rope (with hooks) which can endure the
weight of the device.
Because the position of using hooks is subject to the size
of the drying hopper, please confirm the type of your
device.
To Next Page
