Chapter 3 Installation
- 29 -
Step
Item Task
7 Installing drying
hopper
Install the main body to the base as shown in Figure.
【Caution！】
・Before installing main body, be sure that slide gate of the
base is securely set.
・Fix the body with 4 bolts securely.
HD-10，15 type base
HD-25～100 type base
HD－150～300 type base
Picture 32
