Mattei BLADE 1 - Table of Contents

III
TI015G0013
BLADE 1-2-3
General Index
GENERAL INFORMATION ................................................................................................11
PURPOSE OF DOCUMENT ................................................................................................................................................ 12
GENERAL NOTES ON DELIVERY...................................................................................................................................... 14
SETTINGS TO BE MADE BY CUSTOMER ....................................................................................................................... 17
SAFETY ..............................................................................................................................21
DANGERS AND RESIDUAL RISKS ................................................................................................................................... 21
RESPONSIBILITIES ................................................................................................................................................................ 23
DESCRIPTION OF PICTOGRAMS ..................................................................................................................................... 24
DESCRIPTION OF MACHINE ............................................................................................31
TRANSPORTATION AND HANDLING INSTALLATION ...................................................41
POSITION OF COMPRESSOR ............................................................................................................................................ 41
ELECTRICAL CONNECTION .............................................................................................................................................. 41
CONNECTION TO THE AIR DISTRIBUTION SYSTEM ............................................................................................... 42
DIMENSIONS OF COMPRESSED AIR DISTRIBUTION PIPINGS ............................................................................ 42
SAFETY DEVICES ..............................................................................................................51
USE OF COMPRESSOR .....................................................................................................61
CHECKS BEFORE START ..................................................................................................................................................... 61
START/ STOP .......................................................................................................................................................................... 61
MAINTENANCE .................................................................................................................71
PERIODIC BASIC CHECKS .................................................................................................................................................. 71
PARTS TO BE REPLACED PERIODICALLY ..................................................................................................................... 72
MACHINE CLEANING .......................................................................................................................................................... 73
LUBRICANTS .....................................................................................................................81
TROUBLESHOOTING ........................................................................................................91
THE ELECTRIC MOTOR .................................................................................................. 101
STORAGE AND DISMANTLING ..................................................................................... 111
ATTACHMENTS .............................................................................................................. 121
MAIN COMPONENTS ........................................................................................................................................................121
OVERALL DIMENSIONS....................................................................................................................................................122
FLOWCHART ........................................................................................................................................................................125
ELECTRICAL WIRING .........................................................................................................................................................126
TECHNICAL DATASHEET ..................................................................................................................................................128
