16
CLEARING JAMMED STAPLES
6
Remove the jammed staples.
7
Push back the face plate until it “clicks”.
①
②
Clicks
Clicks
8
Attach the cartridge. When this is
done, push it in rmly until it “clicks”.
Clicks
9
Close the rear cover.
10
Connect the power plug, turn on the power
switch, check that the green LED indication
lamp is blinking, and hold down the START
button (approx. 3 seconds). Continuous
operating sound will be heard, but this is
because the staple rell is moving to the
stapling position, not a mechanical problem
.
☆ If the jammed staples cannot be cleared in the above-mentioned procedure,
disconnect the power plug immediately from the plug socket and ask your dealer or
distributor for repair.
Hold
down
To Next Page
