i-HP Industrial inverter air/water heat pumps with axial fans
24
TECHNICAL CHARACTERISTICS
Unit
i-HP
0250F
0250F
Integrated
circulator
0260
0260
Integrated
circulator
0270
0270
Integrated
pump
Electric data
Power supply
400V/3P+N+T/50Hz
400V/3P+N+T/50Hz
400V/3P+N+T/50Hz
Maximum power input
kW
28,62
29,09
31,19
31,92
34,12
35,12
Maximum current input
A
41,4
42,1
45,1
46,1
48,2
50,7
Cooling
Cooling capacity (1)
kW
49,11 (52,1*)
49,32 (51,8*)
57,20 (60,6*)
57,14 (60,6*)
70,11 (71,5*)
70,76 (72,2*)
Power input (1)
kW
12,27
12,06
14,01
14,07
18,47
18,62
EER (1)
W/W
4,00
4,09
4,08
4,06
3,80
3,80
Cooling capacity (2)
kW
36,21 (38,4*)
36,36 (38,3*)
43,00 (45,6*)
42,97 (45,6*)
53,30 (54,9*)
53,40 (55,0*)
Power input (2)
kW
12,49
12,45
13,72
13,75
17,20
17,25
EER. (2)
W/W
2,90
2,92
3,14
3,12
3,10
3,10
SEER (5)
W/W
3,95
4,16
4,05
Heating
Heating capacity (3)
kW
48,46 (51,4*)
48,25 (51,2*)
52,00 (55,1*)
52,04 (55,1*)
65,10 (66,4*)
65,20 (66,5*)
Power input (3)
kW
11,63
11,42
12,60
12,64
16,09
16,10
COP (3)
W/W
4,17
4,22
4,13
4,12
4,05
4,05
Heating capacity (4)
kW
41,26 (43,7*)
41,07 (43,5*)
49,30 (52,3*)
49,33 (52,3*)
60,34
(62,15*)
60,45
(62,25*)
Power input (4)
kW
12,2
12,07
15,12
15,15
18,86
18,90
COP (4)
W/W
3,37
3,40
3,26
3,26
3,20
3,20
SCOP (6)
W/W
3,82
4,00
3,82
Energetic class
Water temp. 35°C / 55°C
Class
A+ / A++
A+ / A++
A+ / A++
Compressore
Brand
Mitsubishi
Mitsubishi
Mitsubishi
Type
Scroll DC inverter + ON-OFF
Scroll DC inverter
Scroll DC inverter
Number
1 + 1
2
2
Refrigerant oil (type, quantity)
mL
FV50S, 4600 totale
FVC68D, 4600 totale
FVC68D, 4600 totale
Fan motor
Type
Motore DC Brushless
Motore DC Brushless
Motore DC Brushless
Number
1
1
1
Rated power input (2)
kW
1,10
1,58
1,78
Max power input
kW
1,78
1,95
2,11
Max current input
A
2,57
2,85
3,08
Fan Speed
r/min
670
770
830
Rated air flow
m
3
/s
6,94
7,72
8,28
Refrigerant
Type
R410A
R410A
R410A
Refrigerant quantity
kg
15,5
16,7
18
Equivalent amount of CO2
ton
32,36
34,87
37,58
Design pressure (high/low)
MPa
4,15/2,7
4,15/2,7
4,15/2,7
Circuito
idraulico
Water flow rate (2)
L/s
1,73
1,72
2,06
2,05
2,55
2,55
Available head pressure (2)
kPa
/
70
/
90
/
60
Internal head loss (2)
kPa
48
60
80
Pump rated power input (2)
kW
/
0,44
/
0,73
/
0,7 / 1,0 (1)
Pump max power input
kW
/
0,55
/
0,73
/
0,8 / 1,1 (1)
Pump max current input
A
/
2,05
/
3,20
/
3,5 / 2,5
Hydraulic connections
inch
2”F
2”F
2”F
Minimum volume of water (7)
L
145
173
214
Energy Efficiency Index (EEI)
/
≤ 0,23
/
≤ 0,23
/
/
Rumorosità
Sound power (8)
dB(A)
76,5 / SL 74,5 / SSL 73,6
78,3 / SL 76,5 / SSL 75,6
78,9 / SL 77,1 / SSL 76,3
Sound pressure (9)
dB(A)
59,7 / SL 58,7 / SSL 56,5
61,6 / SL 60,8 / SSL 58,6
63,4 / SL 62,6/ SSL 60,4
Dimensions
and weight
Dimensions (L×H×W)
mm
1198x1745x1198
1198x1745x1198
1198x1745x1198
Packing dimensions (L×H×W)
mm
1200x1890x1200
1200x1890x1200
1200x1890x1200
Operating weight
kg
422
436
438
462
449
473
Net/Gross weight
kg
414/434
428/448
430/450
454/474
441/461
465/485
Operating conditions:
(1) Cooling: Outdoor air temperature 35°C; inlet/outlet temperature 23/18°C.
(2) Cooling: Outdoor air temperature 35°C; inlet/outlet temperature 12/7°C.
(3) Heating: Outdoor air temperature 7°C DB 6°C WB; inlet/outlet temperature 30/35°C.
(4) Heating: Outdoor air temperature 7°C DB 6°C WB; inlet/outlet temperature 40/45°C.
(5) Cooling: water temperature inlet/outlet 12/7°C.
(6) Heating: normal climatic condition; Tbiv=-7°C; eater temperature inlet/outlet 30/35°C.
(7) Calculated in the case of the plant water temperature decreased by 15°C for 6 minutes of defrosting.
(8) Condition (3); the value is determined on the basis of measurements taken in accordance with the UNI EN ISO 9614-2, in compliance with the requirements of
Eurovent certification.
(9) Sound pressure level measured at 1m from the unit, in free field, according to ISO 3744. Also the values with installed accessories SL or SSL are reported.
(10) Packing height including the pallet
(*) With Hz max operation, this function can be activated by the user.
N.B. The performance data are indicative and could be subject to change. In addition, the performances declared in apex (1), (2), (3) and (4) refer to the
instantaneous power according to EN 14511. The declared data stated in the apex (6) is determined according to the UNI EN 14825.
WARNING: The minimum temperature allowed for storing the unit is 5°C.
