MAXA i-HP 0270 - WIRING DIAGRAMS

i-HP Industrial inverter air/water heat pumps with axial fans
35
Electric box opened (i-HP 0260 / i-HP 0270)
The GI module is installed as shown for the electric box i-HP 0250 model’s electric box.
24 WIRING DIAGRAMS
For consulting the wiring diagrams refer to the MSE manual supplied with the unit.
Transformer
Disconnecting switch
with door lock
Cables’ conduits
On-board terminal block
and user’s terminal block
Fuses support
Contactors
Support
board
Driver board
(one for each
inverter
compressor
EMI filters
Power supply
board
User display
Inductance
Resistance
